Equipped With
SSB 40 F Super
SSB 50 F Super
Working Area
Drilling capacity
1.57 in
1.97 in
Tapping capacity, steel
M 24
M 30
Table set up area
21x17 in
23x18 in
Quill stroke
7 in
8 in
Manual table travel
22.44 in
20.87 in
Powered table travel
16.93 in
16.14 in
Table swivel range (max.)
± 45¡
Column diameter
6 in
7 in
Spindle nose-to-table distance (max.)
26 in
23 in
Spindle nose-to-foot distance
47 in
46 in
Throat
13 in
14 in
Headstock
Speed range
60 - 2,600 rpm
50 - 2,200 rpm
Spindle mount
MK 4
Feed
Quill feeds
0,1; 0,2; 0,3; 0,4 (4) in/R
0,08; 0,12; 0,17; 0,24; 0,35; 0,50 (6) in/R
Drive Capacity
Motor rating main drive
2.7 Hp
3 Hp
Measures and Weights
Overall dimensions (length x width x height)
40x26x88 in
46x27x93 in
Weight
1,100 lbs
1,430 lbs
Ideal for drilling, countersinking, reaming and tapping
Very rigid construction with thick-walled column and large throat
Infinitely variable speed adjustment and digital speed display
4 automatic drill feeds with electromagnetic clutch control and automatic shut-off when reaching the limit stop
Motorized table height adjustments
Digital boring depth display
Large drilling table with circumferential coolant groove, height adjustment, and ± 45¡ swivel range
Tapping unit is Standard equipment
tapping unit
protective shield
LED work lamp
coolant system
operating tools
operator manual
