47” x 79” KENT USA SGS-2012 AHD DOUBLE COLUMN DESIGN SURFACE GRINDER - NEW
PRODUCT FEATURES
47” x 79” working capacity
3-axis automatic movement with incremental downfeed, electronic auto-crossfeed
High tensile precision GB350 Meehanite castings
Full featured NC electronic control on Z axis
Precision hand scrapped double V turcite table ways for smooth and long lasting precision
High column design with 37.4” spindle center to table for extra clearance under the wheel
Centralized automatic lubrication system provides lubrication to all points
Safety 24V control circuit power
STANDARD ACCESSORIES
Grinding wheel
Wheel flange
Wheel balancing base
Wheel balancing arbor
Diamond dresser base
Magnetic separator & paper filter coolant
Electromagnetic chuck & control
Toolbox with tools
NC Z-axis controller
Hydraulic overhead parallel dresser
OPTIONAL ACCESSORIES
DRO system
Static Wheel Balancing Base
Working Surface
Grinding Surface
Horizontal Travel
Distance Between Two Columns
Distance Between Table Surface and Spindle Center
Distance Between Table Surface and Wheel Top
Inclination of Universal Head
Table Speed
Automatic Crossfeed of Spindle Seat (60 Hz)
Downfeed Handwheel Min Scale
Crossfeed Handwheel (1 gra)
Crossfeed Handwheel (1 rev)
Longitudinal Travel
Crossfeed Travel
Spindle Motor (H. Axle)
Spindle Motor (V. Axle)
Hydraulic Pump Motor
Crossfeed Motor
Downfeed Motor
Grinding Wheel (OD x T x ID) (H. Axle)
Grinding Wheel (OD x T x ID) (V. Axle)
Grinding Wheel (OD x T x ID) (H. Axle)
Grinding Wheel (OD x T x ID) (V. Axle)
Flow Rate of Coolant Pump
Max Load Capacity
Net Weight
SGS-2012AHD / T2012AHD
47.2" x 78.7"
51.2" x 82.7"
86.6"
63" ~ 75"
45.3"
33.5"
±90°
5 ~ 25M/min (16 ~ 80 ft/m)
0 ~ 1"
0.0002"
0.001"
0.2"
7.9" x 90.6"
0" ~ 55.1"
20HP x 4P (Opt. 30P x 4P)
10HP x 4P (Opt. 15HP x 4P)
15 HP x 6P
1/4 HP x 6P
DC Servo
20" x 2" x 5" (Opt. 20" x 3" x 8")
16" x 2" x 5"
1250 RPM / 1050 RPM
1750 RPM / 1450 RPM
90 L/min
8360 lbs
46100 lbs
