16" x 40" KENT USA RML-1660VT MANUAL PRECISION LATHE - NEW
PRODUCT HIGHLIGHTS
5 HP main spindle motor
36-1800, 12 steps spindle speeds
Hardened and ground gears and bedways
Cast iron machine bedways with full one piece cast base and front loading chip tray for easier cleaning
Foot brake and T-Slot compound Inch/metric reading on dials
Inch/metric ruler on tailstock quill
ISO 9001 certified manufacturer
STANDARD ACCESSORIES
3-jaw chuck (9″)
Steady rest
Follow rest
4-position tool post
Coolant system
Full-length splash guard
Worklight
Chuck cover
Thread chasing dial
Toolbox with standard tools
OPTIONAL ACCESSORIES
4-jaw chuck (10″)
Digital Readout System
Royal spindle type live center
BTC 3-jaw chuck with back plate
Taper turning attachment
Rustlick coolant
Micro carriage stop
Face plate (12″ D1-6)
Transformer for 440V power (5 KVA)
Swing Over Bed
Swing Over Cross Slide
Swing Over Gap
Width of Bed
Distance Between Centers
Cross Slide Travel
Top Slide Travel
Spindle Speeds
Spindle Speed Range
Through Hole Diameter
Spindle Nose
Spindle Bore Taper
Thread – Standard (Whit-worth)
Thread – Metric Pitch
Longitudinal Feed
Cross Feed
Lead Screw Diameter
Threading Pitch
Quill Travel
Quill Diameter
Quill Bore Taper
Main Motor
Coolant Pump Motor
Machine Dimension
Packing Dimension
Machine weight
Packing weight
RML-1660VT
16-3/16"
10-3/8"
23"
10.25"
60"
8-11/16"
5.5"
Inf. Variable
20-2500 RPM
2-1/16"
D1-6 Camlock
MT#6
45 (2-72) TPI
39 (0.2-14) mm
.002" - .067"
.001" - .034"
4/5"
4 TPI
6"
2"
MT#4
5 HP (7.5 HP Optional)
1/8 HP
99" x 40" x 62"
105" x 44" x 66"
3740 LBS
4180 LBS
