| Table Size-W | 9" | 228.6 mm |
| Table Size-L | 49" | 1,244.6 mm |
| Power | 3 hp | 2.2 kW |
| Dimensions | 6′ L x 6′ W x 7.5′ H | 6′ L x 6′ W x 7.5′ H |
| Weight | 2,750 Approx. | 2,750 Approx. |
TABLE SIZE: 9" x 49"
LONGITUDINAL TRAVERSE: 34"
CROSS TRAVERSE: 12"
RAM TRAVERSE: 12"
VERTICAL TRAVERSE: 16"
QUILL TRAVEL: 5"
QUILL DIAMETER CHROMED: 3-3/8"
QUILL POWER RATE: 0.0015", 0.003", 0.006"/REV.
SPINDLE TAPER: R-8 with ABEC-7 Bearings
SPINDLE MOTOR: 3 HP INVERTER MOTOR
SPINDLE SPEED: VARIABLE SPEED (0 ~ 500 ~ 4500 RPM)
Power Draw Bar
DRO
Power Table
One Shot Lube
