NEW HYD-MECH H-40/65

Equipped With
NEW 40"H x 65"W HYD-MECH H-40/65 HORIZONTAL BAND SAW


The H-40/65 has a workload capacity of 50,000 lbs. A 5 HP driven hydraulic pump supplies system pressure through 3-position directional valves controlling all vising, head up/down, blade tension, guide arm, and shuttle movement.
Its PLC control digitally displays blade speed, feed rate, head up limit position, and cut elapsed time, and time remaining.
Featuring a 40″H x 65″W capacity, 20 HP motor, and 3″ blade, the H-40/65 is a reliable choice for all your heavy-duty horizontal metal cutting applications.


SPECIFICATIONS
Rectangular Capacity At 90º
40"H x 65"W
Blade Size
3" x 40'4"
Blade Drive
20 HP VFD
Operation
Manual
