NEW 30" x 120" SHARP MODEL 30120V PRECISION ENGINE LATHE
3 preloaded high precision “TIMKEN” tapered roller bearings, 2 in the front and 1 in the rear to ensure accuracy under radial and axial cutting force support the spindle.
All gears in the headstock and the gearbox are made out of Nickel-Chromium alloy steel, hardened and ground for wear resistance.
The 4-1/8” hole spindle provides large chucking capacity with D1-11 camlock nose.
Electro-magnetic brake is installed in the headstock for fast braking of the spindle.
A splash lubrication system is used for ensuring the gear train with smooth and quiet operation.
The carriage is equipped with rapid traverse function with safety protection, for easy positioning of the work piece along the bed way.
The cross slide is equipped with 2 fully adjustable tapered gibs to provide wear compensation and adjustment.
The leadscrew and nuts of the cross slide run in oil bath for constant lubrication.
The gearbox offers a wide range of threads. It offers 60-inch threads, from 1/4 TPI to 84 TPI. A total of 230 threads, inch, metric, DP and MO threads are available. The selection of each thread is achieved by shifting the proper levers, no need to change any end gears outside the headstock.
The tailstock quill has a 4:1 reduction ratio to provide the extra push in heavy drilling. It is graduated with dial for accurate control of quill feed. It has a key-way lock that prevents twisting during heavy drilling work.
Swing over bed
30"
Swing over cross slide
14-3/4"
Swing over gap, width
33", 39"
Distance between centers
120”
HEADSTOCK
Spindle nose type
D1-11 CAMLOCK
Spindle bore/hole
4-1/8" Diameter
Taper of hole in spindle nose
MT#5
Spindle speeds (18 changes)
10-1200 rpm
THREADS AND FEEDS
Inch threads [#]
1/4 - 84 TPI (60 threads)
Metric and module threads [#]
0.2 - 112 mm (60 Threads)
DP Threads
1 - 240 DP (55 Threads)
MP Threads
0.05 - 28 MP (55 Threads)
Longitudinal feeds
0.0015 - 0.2 in/rev
Cross-feed
0.0006 - 0.16 in/rev
Lead screw Diameter/Pitch
1-1/2" / 2 TPI
CARRIAGE
Crosslide travel
14-3/4"
Compound rest travel
9"
Size of Carriage
30-1/4" Width x 26-3/4" Length
BED
Bed width
19"
Bed height
15-3/4"
TAILSTOCK
Quill diameter
3-1/8" Diameter
Quill travel
7-1/2"
Quill taper
MT#5
GENERAL
Spindle motor
15 HP (220V or 440V, 60,3)
WT. (approx.)
8,200 lbs
STANDARD ACCESSORIES:
Face Plate (20”)
Steady rest with roller jaws (8"-13")
Coolant system
Longitudinal carriage stop
Halogen work light
OPTIONAL ACCESSORIES:
3 Jaw chuck (16”, 20”)
4 Jaw chuck (20”)
Roller jaws for steady rest
Follow rest
Quick-change tool holder
Live centers
Micrometer carriage stop
Taper attachment
Tracer attachment
