NEW SHIGIYA GAE-30

Equipped With
NEW SHIGIYA GAE-30  CNC ANGULAR CYLINDRICAL GRINDER


The GAE-30 versatile type CNC angular cylindrical grinder is renowned for high efficiency and high accuracy on the mass-production line. Designed for flexibility and ease of use, it excels at grinding end surfaces and cylindrical surfaces of shafts with the journals and their shoulders. It is equally well suited to general universal grinding of cylindrical or conical surfaces on rotational parts.
.
Swing Over Table
11.81"
Distance Between Centers
9.84" / 19.69" / 29.53" / 39.37" / 59.06" / 78.74"
Weight Capacity
330.69 Lbs
Wheel Size OD
17.91" / 20.08"
Wheel Size Width
1.97"- 3.94"
Wheel Spindle
7.38 HP / 10.06 HP
Machine Weight
6613 Lbs / 7716 Lbs / 8818 Lbs / 9920 Lbs / 11684 Lbs / 13448 Lbs
