Equipped With
Working Area
Grinding diameter
1 in
Speed
5,200 rpm
Collet chuck diameter
0.7 in
Taper grinding
0¡ ~ 180¡
Rear angle
0 ~ 45 deg
Hand-wheel rotation, spindle
0.3 in
Hand-wheel rotation, tool holder
0.7 in
Travels
Travel tool holder
6 in
Drive Capacity
Motor rating main drive
0.2 Hp
Measures and Weights
Grinding wheels dimensions
4x2x1 in
Overall dimensions (length x width x height)
18x16x14 in
Machine weight
123 lbs
Base weight
37 lbs
Part No.
102880
base
wheel mount
grinding wheel
spare parts list
collets 3, 0.16", 0.24", 0.31", 0.39"
operating tools
operator manual
test certificate
