| Swing | 9.45" | 240.03 mm |
| Max Grinding Bore | 3.15" | 80.01 mm |
| Travel-Long | 13.78" | 350.01 mm |
| Workhead Swivel | +45 to -10 | +45 to -10 |
| Workhead Power | 1.6 hp | 1.2 kW |
| Wheel Power | 3 hp | 2.2 kW |
| Workhead Speed | 0 RPM | 0 RPM |
| Dresser | Yes | Yes |
| Control | CNC (Mitsubishi M80) | CNC (Mitsubishi M80) |
| Dimensions | 84.65 x 68.9 x 73.23 | 84.65 x 68.9 x 73.23 |
| Weight | 6614 | 6614 |
Wheel spindle surface detecting & crash control system (current indicator)
Grease type grinding wheel spindle: (Select 2 pc from 8,000~50,000RPM)
Hydraulic 8" 3-jaw chuck
MPG handwheel: EGM 3 Axes control
X Axis Heidenhain linear scale (resolution 0.05 um)
Electricity cabinet w/ heat exchanger
Workhead spindle A2-6 (2.55" thru-hole)
Automatic lubrication system
4-color indication signal light
Levelling bolts and blocks
Tools & tool box
Electrical wiring diagram
Operation manual & part lists
Full-enclosed splash guard
Coolant system with magnetic separator & paper filter
LED working light
Three-direction dresser stand x 1 set, diamond dresser x 3 pcs
