USED 2000 YAMAZAKI HEAVY DUTY 34
Overview
MAZAK (YAMAZAKI) 34 HEAVY DUTY DOVE TAIL WAYS, 34" SWING x 80" CENTERS ENGINE LATHE WITH ALL OPTIONS * 21-INCH 3-JAW PRECISION SELF CENTERING MANUAL SCROLL CHUCK WITH TOP JAWS REMOVED HEAVY DUTY CONSTRUCTION WITH TAILSTOCK * Lathe Fully Installed Under Power in Plant Moving Sale New Reduced Pricing
* SPECIAL TIMING PRICE ON SHOP DIV. CLOSING.
* FULLY INSTALLED UNDER POWER FOR INSPECTION.
Specs
MAZAK (YAMAZAKI) 34 HEAVY DUTY DOVE TAIL WAYS, 34" SWING x 80" CENTERS ENGINE LATHE WITH ALL OPTIONS * 21-3- PRECISION SELF CENTERING MANUAL SCROLL CHUCK 10K Option Est. Mfg. 2000
MAIN SPECIFICATIONS:
SWING OVER BED WAYS ................ 34"
SWING IN REMOVABLE GAP ......... 44"
SWING OVER CROSS SLIDE .......... 24-1/2"
DISTANCE BETWEEN CENTERS ... 80"
HOLE THRU SPINDLE .................... 4-1/16"
SPINDLE NOSE ............................... D1-11" CAMLOCK
WIDTH OF BED ................................22"
SPINDLE SPEED RANGE (16) ........ 12 - 1200 RPM
LONGITUDINAL FEED RANGE ...... .00217" - .0331" IPR
CROSS FEED RANGE HALF OF LONGITUDINAL SETTING
INCH THREADING RANGE (40) ..... 4 - 56 TPI
METRIC THREADING RANGE (23) .5 - 7 mm
TAILSTOCK SPINDLE TRAVEL ...... 8"
TAILSTOCK SPINDLE TAPER ........#6MT
APPROXIMATE FLOOR SPACE .... 144"L x 60"W x 60"H
APPROXIMATE WEIGHT ...............12,500 LBS
Equipped With
INCH & METRIC THREADING
GAP REMOVED
21" 3-JAW CHUCK SCROLL SELF CENTERING
ALORIS TOOL POST
TAIL STOCK
HARDENED & GROUND BED WAYS
20 H.P MAIN MOTOR
ALL AVAIALBLE WORK HOLDING IS INCLUDED
SPECIAL REDUCED PRICE:... $ Please Email Request
