USED 2011 MORI SEIKI NHX-5000

2 Pallet Changer System
1 Degree Indexing of Rotary Table
High Pressure Coolant Through the Spindle - (Chip Blaster)
Chip Conveyor
OTS Tool Touch Sensor Probe
60 Station Tool Changer
12,000 RPM Spindle
Remote Jog Handle
Flood Coolant System
Rigid Tapping
USB Port Interface
RS 232 Port Interface
All Available Manuals

The 2011 Mori Seiki NHX-5000 CNC Horizontal Machining Center offers reliable performance and impressive precision suitable for various industrial applications. With dual pallets measuring 19.7" x 19.7", it allows for seamless operation and improved productivity. Featuring a Mitsubishi MSX 853 IV control with MAPPS, the machine supports advanced machining requirements with ease and precision.

Equipped with a robust 40 HP spindle motor, the NHX-5000 delivers a spindle speed of up to 12,000 RPM, efficiently handling complex tasks. Its tool magazine capacity is noteworthy with a 60-station tool changer, providing flexibility for diverse machining operations. The machine accommodates a maximum weight of 882 lbs on the table, which, combined with a cutting feedrate of 984 IPM and rapid traverse rates of 2,362 IPM, ensures swift and effective processes.

With an X-axis and Y-axis travel of 28.7" and a Z-axis travel of 34.5", coupled with 1-degree pallet indexing, the NHX-5000 enables versatile machining of parts with intricate dimensions. Structurally robust, the machine dimensions are 215" x 132" x 122", and it weighs 33,000 lbs, signifying its stability and durability in high-demand settings. Overall, this machining center is engineered to provide exceptional cutting performance and precise results.

Machine Control: Mitsubishi MSX 853 IV with MAPPS
Pallet Size / Number of Pallets: 19.7" x 19.7" / 2 Pallets
Maximum Weight on Table: 882 lbs.
Maximum Workpiece Height: 35.4"
Pallet Indexing: 1 Degree Indexing
X-Axis Travel: 28.7"
Y-Axis Travel: 28.7"
Z-Axis Travel: 34.5"
Spindle Nose: CAT #40 Taper
Spindle Speed: 12,000 RPM
Spindle Motor: 40 HP
Tool Magazine Capacity: 60 Station Tool Changer
Maximum Tool Diameter / Length / Weight: 6.6" / 17.7" / 18 lbs.
Rapid Traverse Rates: 2,362 IPM
Cutting Feedrates: 984 IPM
Machine Dimensions LxWxH: 215" x 132" x 122"
Machine Weight: 33,000 lbs
