NEW JIH-I JIH-CNC8500H
Overview
Description
The JIH-CNC8500H is a heavy-duty traveling column CNC machining center designed for precision, power, and reliability. Engineered with a fixed table and traveling column configuration, this machine ensures consistent machining accuracy regardless of workpiece weight—making it an ideal choice for large part processing across industries such as aerospace, automotive, mold making, and general manufacturing.
Key Features:
• The base is fabricated from heavy gauge steel plates and scientifically reinforced, allowing for solid support for the column and work pieces.
• Travelling column design features increased machining efficiency and accuracy.
• The oversized box-type column is manufactured from high quality cast iron.
• Large diameter ball screw on x-axis is firmly supported to eliminate self-deflection problems.
• 3 axis adopt 45 mm P class high precision linear guide ways; X axis features 8 blocks, Y and Z axis are 6 blocks.
• Automatic lubricator delivers lubrication oil to all linear ways and bal screws.
• Y-axis & X-axis ball screws are direct coupled with drive motors, featuring no backlash, high transmission efficiency and high accuracy.
Travelling Column
• The machine is designed with a travelling column and a fixed table.
• With the travelling column configuration, work piece weight will not affect the transmission system. As a result, consistent machining accuracy can be achieved.
• Each linear way on the Y-axis is fitted with 3 sliding blocks to assure ultra-high stability when the Y-axis is moving
Specifications
| X-axis Travel | 8,500 mm | 334.65" |
|---|---|---|
| Y-axis Travel | 650 mm | 25.591" |
| Z-axis Travel | 700 mm | 27.559" |
| Spindle Nose to Table Dist. | 1,100 mm | 43.307" |
| X-axis Feedrate | 40 m/min. | 1,574.8 in/min. |
| Y-axis Feedrate | 24 m/min. | 944.9 in/min. |
| Z-axis Feedrate | 24 m/min. | 944.9 in/min. |
| Table Size | 600 x 9500 MM | 600 x 9500 MM |
| Table Load | 2,500 kg | 5,511.6 lb |
| Spindle Speed | 12,000 RPM | 12,000 RPM |
| Spindle Taper | HSK-A63 | HSK-A63 |
| ATC Magazine | 40 Tools | 40 Tools |
| Motor | 20 hp | 14.9 kW |
| ATC Type | Arm Type | Arm Type |
| Max Tool Length | 300 mm | 11.811" |
| Max Tool Dia | 80 mm | 3.1496" |
| Max Tool Weight | 7 kg | 15.4 lb |
Equipped With
FANUC 0i-MF PLUS CONTROL W/ 15" LCD SCREEN
AICCII (200 BLOCK) + 2GB DATA SERVER
SPINDLE NOSE TO TABLE SURFACE: 400 - 1100 MM
SPINDLE NOSE TO 4-AXIS CENTER: 80MM - 780 MM
TABLE TYPE: 5 GROOVE T-SLOTS TABLE
WORKTABLE EXTENDED TO 9,500 MM
T-SLOTS (NO./W/P): 5/94/600 MM
WORK TABLE LOWER 300MM
12,000 RPM SPINDLE SPEED, HSK-A63
SPINDLE MOTOR 20 HP
40 TOOLS ATC MAGAZINE
40 PULL STUD
FULLY ENCLOSED (NO ROOF)
CHIP CONVEYOR
UPGRADED TO 70 BAR COOLANT THROUGH SPINDLE SYSTEM (WITH MANUAL VARIABLE FLOW)
OIL SKIMMER
CONTROLLER MOVING ALONG THE X-AXIS FROM OUTSIDE MACHINE 8.5M
4th AXIS PREPARATION
RENISHAW LASER TOOL MEASUREMENT SYSTEM NC4
REMOVABLE PARTITION BETWEEN TWO WORKING AREAS
