USED TRIA TR-120-49

🏭 Manufacturer Information

Manufacturer: Tria

Model: TR 120-49

Type: High-Capacity Industrial Granulator

Condition: Used

⚙️ Product Description

This Used Tria TR 120-49 Granulator is a heavy-duty size-reduction system engineered for high-volume processing of plastics, film, sprues, runners, sheet, and thermoformed materials. With throughput capability up to 1,200 kg/hr (depending on material and screen size), it is ideal for demanding industrial environments.
The granulator features a 490 mm rotor diameter and 1,200 mm rotor width, with an open-rotor design containing 5 rows of 2 knives (10 knives total). The cutting chamber includes 4 stator knives (2 front, 2 rear) for efficient, clean cuts.
A water-cooled cutting chamber supports thermal stability during continuous operation, while the rear trap-door feed system makes it well-suited for thermoforming scrap. The unit is enclosed in a sound-insulated steel enclosure with hinged access doors for quieter operation and easier maintenance.
Powered by a robust 50 HP (≈37 kW) motor, this granulator is designed for industrial reliability and consistent particle-size reduction.

📏 Specifications

Model: TR 120-49

Rotor Diameter: 490 mm

Rotor Width: 1,200 mm

Feed Opening: Approx. 970 mm W × 120 mm H

Rotor Type: Open rotor

Rotor Knives: (5) rows × (2) knives = 10 knives

Stator Knives: (2) front + (2) rear = 4 total

Throughput Capacity: Up to 1,200 kg/hr

Cutting Chamber: Water-cooled

Discharge: Large throughput-optimized screen

Enclosure: Fully sound-insulated steel housing with hinged doors

Drive Motor: 50 HP (approx. 37 kW)

Electrical: 3/60/460–480V

🧩 Applications

Plastics recycling

Film and sheet scrap reduction

Thermoforming line integration

Injection molding & extrusion waste

Pipe, profile, and purging granulation

Recycling plants

Industrial compounding operations

Packaging material reduction

Fiber & light-material granulation

Regrind production

⚗️ What Might This Be Used For

Reducing plastic waste into uniform regrind

Feeding downstream extrusion or compounding systems

Inline thermoforming scrap granulation

High-capacity plastics recycling lines

Energy-efficient size reduction with water-cooled chamber

🧱 Materials It Can Process

PET, PP, PE, PS

Film, sheet, web trim

Thermoformed scrap

Sprues / runners

Engineering plastics

Nylon & polycarbonate (with proper setup)

Soft and rigid plastics

Packaging plastics

Flexible materials

Recycled commodity plastics
