Overview
Type:
Press Brakes
Manufacturer:
HANS SCHOEN
Model:
NH 160
Year:
1988
Stock #:
757240
Description

Manufacturer: Hans Schoen
Model: NH 160
Year of Manufacture: 1988 rebuilt in 2016
The press is being sold without tools or spare parts.

Technical Data
Press force max.: 1,600 kN
Main drive power: 30 kW

Speeds
Rapid advance from: 300 mm/sec
Pressing speed: 18 mm/sec
Rapid return: 300 mm/sec

Strokes
Max. stroke: 150 mm
Max. daylight opening: 450 mm

Table and Ram Dimensions
Ram area: 730 × 560 mm
Table area: 650 × 650 mm

Openings
Front vertical opening: 750 mm
Side vertical opening: 250 mm

Heights
Table height above floor: 850 mm
Table bore diameter: 150 mm
Ram bore, Ø H7: 60 mm

T-slots
T-slots in table, DIN 650 H12 diagonal: 22 mm
T-slots in ram, DIN 650 H12: 22 mm
Two pieces, front to back

Machine Dimensions
Machine footprint approx.: 1,850 × 1,500 mm
Machine height approx.: 2,850 mm
