PEDDINGHAUS MEBA HEAVY DUTY AUTOMATIC HORIZONTAL BAND SAW, Model 1000-1000A, Meba CNC Control, 39.37" x 39.37" Rectangular Capacity, 39.37" Round Capacity, Horizontal & Vertical Hydraulic Vise, 19.5 HP, Max 492 FPM, 15' Infeed Conveyor, 30' Outfeed Conveyor, Coolant Pump, Chip Conveyor, New 2008.
| Nominal Capacity (H) | 39.37" | 1,000 mm |
| Nominal Capacity (W) | 39.37" | 1,000 mm |
| Round Capacity | 39.37" | 1,000 mm |
| Square Capacity | 39.37" | 1,000 mm |
| Type (Auto, Manual, Semi) | Auto | Auto |
| Blade Speeds | 49-492 ft/min. | 49-492 ft/min. |
| Blade Length | 434.84" | 11,045 mm |
| Max Blade Width | 2.64" | 67.056 mm |
| Blade Thickness | 0.06" | 1.524 mm |
| Vise | Hydraulic Vertical & Horizontal | Hydraulic Vertical & Horizontal |
| Blade Tension | Hydraulic | Hydraulic |
| Blade Drive Power | 19.4 hp | 14.5 kW |
| Electrics | 460/3/60 | 460/3/60 |
| Working Height | 24.8" | 629.92 mm |
| Dimensions | 236.22" x 181.1" x 147.64" | 236.22" x 181.1" x 147.64" |
| Weight | 30,865 lbs | 30,865 lbs |
Model 1000-1000A, Meba CNC Control, 39.37" x 39.37" Rectangular Capacity, 39.37" Round Capacity, Horizontal & Vertical Hydraulic Vise (Bundling), 19.5 HP, Max 492 FPM, 15' Infeed Conveyor, 30' Outfeed Conveyor, Coolant Pump, Chip Conveyor.
