Mega Punch SMGP-35, 35-ton hydraulic press. Features 18" throat, 4" stroke, 30 strokes/min, and 24"x38" table. Powered by 5 HP motor, currently 220V. Includes quick-change tooling and foot pedal. Total weight: 2,500 lbs.
| Tonnage | 35 T | 31.752 t |
| Throat | 18" | 457.2 mm |
| Weight | 2500 Lbs. | 2500 Lbs. |
Brand: Mega punch
Model: SMGP-35
Specifications:
Capacity: 35 tons
Stroke length: 4"
Open height: 11-5/8"
Closed height: 7-5/8"
Working height: 42"
Strokes per minute: 30
Throat depth: 18"
Main motor: 5 H.P.
Voltage: 220 / 440 volt 3 phase (currently wired 220 volt)
Weight: 2,500 Lbs.
24" x 38" table
Quick change tooling
Portable foot pedal
Stroke length adjustment
