NEW AKYAPAK ASM-S 140-20/4
Overview
Description
The ASM 3 roll plate rolling machine is made with a cast iron body. Central rollers are powers. This well built, high performance machine is made in Europe and uses standard quality components found on the market.
• Body of cast iron construction
• Central rollers powered with electric motor and gear drive
• Cone bending device
• Self brake main motor
• Top roller can be manual opened to the side
• Lower and back roll are in height adjustable by hand
• Separate electric control panel with foot pedal
• Back roll with Motor (option included)
• Induction hardened rolls (option included)
• Digital display (option included)
Specifications
| Length of Rolls | 6.5' | 2 m |
|---|---|---|
| Max Thickness (gauge) | 10 gauge | 10 gauge |
| # Rolls | 3 | 3 |
| Power Rear Roll (Yes/No) | yes | yes |
| Power | 3 hp | 2.2 kW |
| Roll Diameter | 5.51" | 139.95 mm |
Working Length 2050 mm 80.7”
Maximum Thickness 4.5 mm 3/16”
Pre-bending 4 mm 5/32”
Ø min bending 210 mm 8.26”
Top Roll Ø 140 mm 5.5”
Bending speed 5.7 m./min/ 224”/min
Motor Power 2.2KW 4HP
Length 2320 mm 91.3”
Height 1200 mm 48”
Width 900 mm 35.5”
Weight 1530 kg 3373 Lbs
