NEW XCMG XE210U

🚧 XCMG XE210U Hydraulic Excavator — Cummins Powered 21-Ton Class

📞 Call 716-353-3676 for details

If you want a true production-class excavator for sitework, utilities, clearing, rock, and heavy trenching, the XCMG XE210U is the “do-everything” machine in the lineup. It’s built around simple, proven components with the muscle and hydraulic performance contractors expect in the 21-ton class.

✅ Powered by a Cummins Tier 4 Final diesel
This is not a no-name engine — the XE210U runs a Cummins QSB6.7, a platform that’s widely supported and familiar to techs across North America.

⸻

🔥 Engine (Cummins Tier 4 Final)
• Engine model: Cummins QSB6.7
• Cylinders: 6
• Rated power @ 2100 rpm
• SAE J1995: 173 hp @ 2100 rpm
• SAE J1349: 153 hp
• ISO 9249: 153 hp
• Max torque @ 1500 rpm: 800 N·m
• Idle (low–high): 700 – 1200 rpm
• Displacement: 1.8 gal
• Bore x stroke: 107 mm x 124 mm
• Starter: 24V x 7.8 kW
• Batteries / Alternator: 2 x 12V, 150 Ah / 24V, 70A
• Air filtration: Donaldson PSD air filter + pre-filtered dust separator

⸻

⚙️ Hydraulics (Pumps, Flow, Pressure)

Main pumps
• Type: 2 x variable displacement tandem axial piston pumps
• Max flow @ 1750 rpm: 2 x 65.5 gpm

Pilot pump
• Type: Gear pump
• Max flow @ 1750 rpm: 7.1 gpm

Relief valve settings
• Pressure up: 5,076 / 5,511 psi
• Travel: 4,786 psi
• Swing: 3,844 psi
• Pilot: 580 psi

⸻

🧠 Hydraulic Cylinders (Bore x Rod x Stroke)

(As shown on your XE210U spec page)
• Boom (Qty 2): 4.7” x 3.4” x 48.1”
• Arm (Qty 1): 5.3” x 3.7” x 54.6”
• Bucket (Qty 1): 4.5” x 3.4” x 41.7”

⸻

🔄 Swing Performance
• Maximum swing speed: 11.8 rpm
• Maximum swing torque: 51,247 ft-lb

⸻

🏁 Travel / Traction
• Travel speed (low–high): 2.2 / 3.5 mph
• Maximum traction: 18.8 ton
• Maximum gradeability: 35° / 70%

⸻

🧱 Undercarriage
• Upper rollers (per side): 2
• Lower rollers (per side): 9
• Links & shoes (per side): 49
• Link pitch: 190
• Overall track length: 14’7”

⸻

💪 Operating Weight / Ground Pressure (Triple Grouser)

(Varies by shoe width)
• 27” shoes: 50,827 lb | 522 ground pressure
• 24” shoes: 50,486 lb | 560 ground pressure
• (narrow shoe option shown): 50,045 lb | 653 ground pressure

⸻

🧊 Fluid Capacities
• Fuel tank: 105.7 gal
• Cooling system (radiator): 6.0 gal
• Urea (DEF) tank: 11.1 gal
• Hydraulic oil tank: 58 gal
• Engine oil: 6.3 gal
• Swing drive: 1.8 gal
• Travel device: 2 x 1.9 gal

⸻

🧰 Component Weights (Key assemblies)
• Upper structure (without front): 31,636 lb
• Lower structure assembly: 18,838 lb
• Front assembly: 7,716 lb
• Counterweight: 9,309 lb
