High Resolution, 3D Color Projection. LayoutMaster delivers precise 3D color projections for connections, holes, and part numbers on various structural steel components.
Drill lines and coping robots mark minimal data and are slow. LayoutMaster optimizes fitting, reduces floor space, and enhances productivity.
The LayoutMaster is a full-color laser projection system that will project all the information that an operator needs to precisely tack-weld connections on the beam or on other connections.
The LayoutMaster is the ultimate, common-sense tool to transform any operator into your best fitter in a matter of minutes!
Imperial / Metric
Width range: 40′–138′ / 12–42 m
Height: 12′ / 3.65 m
CONFIGURATIONS
• Stand-alone
• With BeamMaster Plus
PART SPECIFICATIONS (maximum)
• Width: up to 55″ / 1 397 mm
• Height: up to 70″ / 1 778 mm
