Superior tube processing capabilities for all your processing tasks
Wide range of tube cutting sizes：∅12-240mm
Various type of tube shapes:round tube、square tube、L-profile 、H-profile
Long length of tube cutting: max. raw material length of up to 9.0 m.
Cost-effectively cutting of various tubes
Speed:120m/min
Chuck rotation speed:120r/min
High dynamic performance，faster tube processing efficiency
Versatile automation
Automatic loading raw material quickly and easily
Automatic unloading of long finished part
Easy to operate
Easily accessible with minimum set up
Automatic and efficient nesting of pipes
Robust and Reliable
Standard-equipped pipe support mechanism,ensure the precision of pipe cutting
Standard-equipped dust blowing system,prioritizing worker’s health
Advanced Intelligent Cutting Solutions
Automatic measurement of the tube center,improve the accuracy of pipe cutting
Corner anti-burn function，optimum cutting result
Short tail cutting, save materials and reduce costs
Power 3000W-6000W
X/Y-axis Positioning Accuracy ±0.05mm/m
Cutting Capacity of Round Tube Φ12-Φ240mm
Cutting Capacity of Square Tube 12*12-240*240mm
Weight of Single Tube 300kg
