Build Volume: 13" x 10.6" x 7.9"
Print Bed: Kinematic coupling - Flat to within 80 microns
Laser: In-process inspection, active print calibration, bed leveling
Extrusion System: 1st generation extruder, out-of-plastic and out-of-fiber detection
Power: 100-240 VAC, 150 W
RF Module: Operating Band 2.4 Ghz Wi-Fi Standards B02.11 b/g/n
Plastics available: Onyx, Onyx FR, Onyx ESD, Nylon White, P-PLA, S-TPU
Fibers Available: Carbon Fiber, Carbon Fiber FR, Fiberglass, Aramid Fiber (Kevlar), HSHT Fiberglass
Tensile Strength: 800 MPa (25.8x ABS, 2.6x 6061-T6 Aluminum)
Tensile Modulus: 60 GPa (26.9x ABS, 0.87x 6061-T6 Aluminum)
Layer Height: 100 Micron default, 50 Micron minimum, 250 micron maximum
Infill: Closed cell infill: multiple geometries available
Elger Cloud: Slicer part / build management (other options available at cost)
Security: Two-factor authentication, org admin access, single sign-on
Blacksmith: Adaptive manufacturing platform (additional purchase required)
Weight of Unit: 106 LBS
Machine Footprint : 23" x 19" x 36"
Total Hours: 2
166 Total Completed Prints: 301
