USED 1982 NOMURA B100SR
Overview
Used Nomura B100SR. This pre-owned Horizontal Boring Mill is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Nomura Horizontal Boring Mill we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
Specs
3-Axis Digital Readouts (Easson Brand)
Built In Rotary Table
Full Pendant Control
Hardened Ways
Sliding Way Covers
Spindle Size: 3.94"
Headstock Vertical Travel: 50"
Table Cross Traverse: 60"
Table Long Travel: 43"
Table Size: 45" x 50"
Max Load on Table: 11,000 lbs
RPM: 1760 rpm
Table width: 45"
Table Length: 50"
Spindle Travel: 26"
Quill: 26"
Built-in Rotary Table: 45” x 50”
Spindle Taper: #50 with power clamping
Table Longitudinal Travel: 43"
Max. load on table: 11,000 Lbs.
Rapid Rotation of Rotary Table: 1.3 rpm
Height of Table top from bed bottom: 38.5"
Main Motor: 20 HP
Feed Motor: 50 HP
Operating Voltage: 230/460/3 Phase /60 HZ
Full load current: 49 Amps
Rating Largest Motor: 25 Amps
Equipped With
3-Axis Digital Readouts (Easson Brand)
Built In Rotary Table
Full Pendant Control
Hardened Ways
Sliding Way Covers
