| Roll Diameter | 4.25" | 107.95 mm |
| Roll Width | 8" | 203.2 mm |
| Roll Finish | Modified square grooves from approximately 10MM down to 1MM. | Modified square grooves from approximately 10MM down to 1MM. |
| Roll Gap Adjustment | Roll gap will be adjusted simultaneously or independently. | Roll gap will be adjusted simultaneously or independently. |
| Mill Power | 7.5 | 7.5 |
| Mill Separating Force | Approximately 75,000 LBS | Approximately 75,000 LBS |
| Mill Voltage | 220V | 220V |
| Mill Phase | 3-Phase | 3-Phase |
| Mill Controls | All new electrical controls will be installed including a new variable speed AC inverter. | All new electrical controls will be installed including a new variable speed AC inverter. |
| Mill Tables | Tables will be installed on the entry and exit of the mill. | Tables will be installed on the entry and exit of the mill. |
| Mill Safety | All nip points will be guarded. | All nip points will be guarded. |
| Mill Dimensions | Approximately 42" L x 32" W x 60" H | Approximately 42" L x 32" W x 60" H |
| Mill Weight | Approximately 2,000 LBS | Approximately 2,000 LBS |
