NEW OGURA CLUTCH CO. LTD OPC-10

Ogura Clutch Co. LTD OPC-10 Electromechanical Clutch
Model: OPC-10
Static Torque: 0.741 Ft Lbs.
Max RPM: 1800 RPM
Shaft Size: 7mm
Voltage: 24Vdc
Keyway: D Shaft
Weight: 1.80 Lbs
FAST RESPONSE
The OP series has been designed to provide fast response. Response rates can be further quickened through overexcitation circuits.

SLIP CAPACITY
OP series units are designed to deliver high performance under constant slip conditions.

NO CONTAMINATION
Units are sealed which prevents any wear particles from contaminating the machine, and also prevents contamination of the clutch by the machine environment.

STABLE TORQUE
The OP series produce consistent and repeatable torque. Torque is independent of speed and proportional to voltage applied to the field.

LONG LIFE
The OP series unit's sturdy construction and precise formulation of the magnetic particles combine to provide extended life.

STABLE TORQUE

The OP series produce consistent and repeatable torque. Torque is independent of speed and proportional to voltage applied to the field.

LONG LIFE

The OP series unit's sturdy construction and precise formulation of the magnetic particles combine to provide extended life.

SKU: IP545328129
UPC: 646412783300
Condition: New
Availability: In Stock
Weight: 2.00 LBS
Width: 7.00
(in)
Height: 6.00
(in)
Depth: 7.00
(in)
Shipping: Calculated at Checkout
Type: Magnetic Clutch
Voltage: 24Vdc
MPN: OPC-10
Model: OPC-10
Shelf: G-11
Series: OP
Manufacturer: Ogura Clutch Co. LTD
Country/Region of Manufacture: Japan
GTIN: 646412783300
