Tooling is the same as Geka / Kingsland
Standard punch is dia 22 mm
punching cap: dia 28 x 15 mm / dia 38 x 11 mm
cutting cap: 200 x 20 mm / 300 x 15 mm
angle shear cap: 90° 120 x 120 x 12 mm / 45° 80 x 8 mm
steel bar shear cap: dia 35 / 40 mm
notching cap: 100 x 42 x 10 mm
Bending examples with bending slide (optional): 250 x 15 mm / 500 x 3 mm
Punchingcapacity: 60 ton
Dia x sheetthickness: 28 x 15 mm
Max course: 55 mm
Strokes/min: 26 str/min
Depth of throat: 220 mm
Max hole dia.: 110 mm
Work level: 940 mm
Max cutting-thickness in plate: 200 x 20 / 310 x 15 mm
Blade length: 380 mm
90°-cut: 120 x 120 x 12 mm
45°-cut: 80 x 8 mm
Work level: 1140 mm
Cut to length round/square: 40 / 35 mm
Cut to length UFN/IPN profiles: 102 x 51 mm
Cut to length Profile T: 80 x 10 mm
Max material -thickness by notching: 10 mm
Max wide by notching: 42 mm
Depth V-profile / rectangle: 100 mm
Electric motor (power): 4 kW
Length: 1510 mm
Depth: 590 mm
Height: 1570 mm
Weight: 1250 kg
