Overview
Type:
Gear Hobbers
Manufacturer:
GLEASON 12
Model:
STRAIGHT BEVEL GEAR
Stock #:
K.01 7858
Description

Maximum distance between cones (face part 2.75" – 3.5") 304.8 mm
Maximum distance between cones (face part 1") 282.6 mm
Minimum distance between cones 0 mm
Maximum indexing angle (bevel gears) 105°
Maximum indexing angle (shafts at 90°) 84° 18′
Maximum indexing angle 5° 42′
Extreme gear ratio 10:1
Maximum surface length 88.9 mm
Slide stroke 12.7 – 107.95 mm
Indexing range (number of teeth) 10–200
Minimum number of teeth for bevel gears 12
Largest module (Pitch) 3 DP (inch pitch, no direct conversion)
Diameter of bevel hole, large side 99.62 mm
Taper per foot length 15.4 mm per 304.8 mm
Depth of cone 152.4 mm
Diameter of hole 400 mm deep 82.55 mm
From spindle to axial line 63.5 – 381 mm
Diameter of through hole 77.79 mm
Tool speed (13 steps) 65–500 strokes/min
Main motor 3 hp, 1800 rpm (~2.24 kW)
Pump motor 1.5 hp, 1200 rpm (~1.12 kW)
Dimensions (L x W) 1930mm x 1422mm
Net weight 6169 kg

Specifications

Weight: 6200 kg
