USED SUNNY MACHINERY SGS-1632AHD 960 X 450 MM
Overview
Specifications
Worklength with magnetic table: 812 x 406 mm
Longitudinal travel X-axis (autom.): 960 mm
Cross-travel Y-axis (autom.): 450 mm
Travel Z-axis (autom.): 620 mm
Dimensions of the table: 800 x 400 mm
Distance between table -- spindlecentre: 620 mm
Max dia grindingstone: 355 mm
Spindlespeeds: 1750 rpm
Motorpower: 7,5 hp
Length: 2780 mm
Depth: 2210 mm
Height: 2250 mm
Weight: 2800 kg
