| Capacity | 0.6" | 15.24 mm |
| Power | 5 hp | 3.7 kW |
| RPM | 10,000 RPM | 10,000 RPM |
| Swiss, Chucker or Convertible? | Swiss | Swiss |
| Main Spindle Indexing | Full C | Full C |
| Sub-Spindle Indexing | Full C | Full C |
Machining Diameter: 5/8″
Machining Length per Chucking: 7 3/4″ (200mm)
Drilling Diameter: 0.23″ Maximum Threading
Diameter (Tap & Die): M6
Main Spindle Speed: 200 – 10000 rpm
Main Spindle Indexing: Full C-Axis
Rotary Spindle on Gang Tool Post:
Drilling Diameter: 0.19″ (Tapping M4)
Spindle Speed: 200 – 8000 rpm
Rotary Spindle on Tool Turret Head:
Drilling Diameter: 0.19″
Threading Diameter: M5
Spindle Speed: 200 – 6500 rpm
Backwork:
Chucking Diameter of Backwork Spindle: 5/8″
Backwork Length: 4.92″
Drilling Diameter: 0.19″
Threading Diameter: M5
Backwork Spindle Speed: 250 – 6000 rpm
Spindle Indexing: Full C-Axis
High Pressure Coolant
Iemca Boss 432/37 Magazine Barfeed
Misc. Tooling
