Baldor CDP3320 .33HP 1750RPM 90VDC 56C 3327P TENV New
Overview
Description
Armature Voltage:
90 V
Base Speed:
1,750 rpm
Enclosure
:
TENV
Frame:
56C
Frame Material:
Steel
Output Power:
0.33 hp
Brand:
Baldor-Reliance
Agency Approvals:
CE, CSA, UR
Ambient Temperature:
40 å¡C
Armature Current:
3.2 A
Armature Inertia:
10.535lb-ft2
Base Indicator:
Rigid
Bearing Grease: Type
POLYREX EM (-20F +300F)
Drip Cover
:
No Drip Cover
Duty Rating
CONT
Feedback Device
:
No feedback
Heater Indicator:
No heater
Lifting Lugs:
No Lifting Lugs
Motor Lead: Exit
KO Box
Motor Lead Quantity/Wire: Size
2 @ 18 AWG, A
Motor Lead Termination:
Flying Leads
Motor Standards
:
NEMA
Mounting Arrangement
:
F1
Overall Length
:
13.19 in
Pulley End Bearing: Type
Sealed Bearing
Service Factor:
1.00
Shaft Diameter:
0.625 in
Shaft Extension Location:
Pulley End
Shaft Ground Indicator
:
No Shaft Grounding
Shaft Rotation:
Reversible
Shaft Slinger Indicator
:åÊ
No Slinger
Specifications
| Weight | 26.00 LBS | 26.00 LBS |
|---|
SKU: IP5278
UPC: 641752899384
Condition: New
Availability: In Stock
Weight: 26.00 LBS
Width: 12.00
(in)
Height: 12.00
(in)
Depth: 14.00
(in)
Shipping: Calculated at Checkout
Hz: 60
Frame: 56C
RPM: 1750
Enclosure Type: TENV
Amperage: 3.2 Amp
Shaft Diameter: 0.625"
Manufacturer: Baldor
Country/Region of Manufacture: United States
