USED NUMATICS SH10602LB16DS4
Overview
Description
Numatics SH10602LB16DS4 Pneumatic Cylinder 1-1/16" Bore 2" Stroke
Comes With 30 Day Warranty.
Primary brandNumatics
Secondary brandEmerson
Main functionPneumatic linear actuator
Product series / family nameGuided line - SH series
Sub-range nameLinear Slides
Bore size1-1/16" bore (B1-1/16")
Stroke length2" stroke length (S2")
Designbumper
Buna-N seals
linear ball bearings
NuMate mounting system
magnetic piston
built-in magnet
included cyl.
adjustable stroke (shaft collars)
Connection type1/8" NPTF threaded pneumatic ports x 2
Length4.44" (tooling plate)
Materialstainless steel 440C cyl. / rod
hard coat anodized 6061-T6511 aluminium body
hardened steel guide shaft
FunctionsDouble-acting pneumatic linear guided slide actuator
Force88lbf (100psi relative working pressure; extend)
81lbf (100psi relative working pressure; retract)
Net width (in)(tooling plate) 1.58 in
Specifications
| Weight | 7.00 LBS | 7.00 LBS |
|---|
SKU: IP06595
UPC: 646412808263
Condition: Used
Availability: In Stock
Weight: 7.00 LBS
Width: 7.00
(in)
Height: 5.00
(in)
Depth: 10.00
(in)
Shipping: Calculated at Checkout
Type: Pneumatic Cylinder
MPN: SH10602LB16DS4
Model: SH10602LB16DS4
Google Manufacturers Part Number: SH10602LB16DS4
Bore Diameter: 1-1/6"
Stroke: 2"
Shelf: B-15
Part Number: SH10602LB16DS4
Max. Pressure: 250 PSI
Manufacturer: Numatics
Useraction: Double
Max. Operating Pressure: 250 PSI
Max. PSI: 250
GTIN: 646412808263
GPS Manufacturers Part Number: SH10602LB16DS4
