NEW NS MAQUINAS DM1600 ZC S-LINE
Overview
Specifications
| Dimensions | 130 X 89 X 87 | 130 X 89 X 87 |
|---|---|---|
| Weight | 8,157 | 8,157 |
NS MAQUINAS (NEW) MODEL DM1600 ZC S-LINE DEBURRING AND EDGE ROUNDING MACHINE
DEBURRS ROUNDS EDGES ON THE INSIDE AND OUTSIDE
CONTOURS OF STAINLESS STEEL, STEEL, OR ALUMINUM
PARTS CUT BY LASER, PUNCHING OR SHEARING
- WIDE BELT HEAD TO REMOVE BURRS
- 2 CROSS BELTS PERFORM EDGE ROUNDING
63" MAXIMUM WORKING WIDTH
4.72" MAXIMUM MATERIAL THICKNESS
2" X 2" MINIMUM PART SIZE
2' - 10'/MINUTE VARIABLE FEED RATE
7.32" DIAMETER CONTACT ROLLER
TWO 2" X 167" BRUSH HEADS
63" X 73" ABRASIVE BELT
26-62 FEET/SECOND GRINDING BELT SURFACE SPEED
MOTORIZED VERTICAL ADJUSTMENT OF TABLE
1 HP CONVEYOR MOTOR
14 HP SANDING BELTS MOTOR
TWO 5 HP CROSS BELT MOTORS
YOU CANNOT MIX ALUMINUM WITH OTHER MATERIALS
MACHINE COMES WITH
- SET OF SANDING BLOCK BELTS W/60P CERAMIC BLOCKS
- 90 DEGREE CROSS BELT
- FREQUENCY INVERTER
OPTIONS AVAILABLE - PRICE ON REQUEST
- 2 REPLACEMENT SANDING BELTS WITH SANDING BLOCKS
- SET OF REPLACEMENT SANDING BLOCKS WITHOUT BELTS
- WET DUST COLLECTOR - MODEL C7SLR - 3700 CFM
- DRY CYCLONE DUST COLLECTOR - A400 - 4000 CFM
