NEW HYDMECH DM-10P

HYDMECH (NEW) MODEL DM-10P SEMI-AUTOMATIC DOUBLE
MITER BAND SAW

CAPACITY - 90 DEGREES
- 9.5" X 11" RECTANGLE, 10" ROUND, 9" SQUARE
CAPACITY - 45 DEGREES - LEFT
- 6.25" X 4.5" RECTANGLE, 5.75" ROUND, 4.5" SQUARE
CAPACITY - 30 DEGREES - RIGHT
- 5" X 4.5" RECTANGLE, 4" ROUND, 5" SQUARE
CAPACITY - 45 DEGREES - RIGHT
- 8.25" X 7" RECTANGLE, 7.25" ROUND, 7" SQUARE

1" X 9' 8" BLADE
2 BLADE SPEEDS
- 118 SFM - 2.4 HP
- 236 SFM - 2 HP
480 VOLTS, 3 PHASE
3.5 GALLON COOLANT TANK
34" TABLE HEIGHT

OPERATOR CONTROL BOX WITH
- SWITCHES FOR SELECTING HEAD FEED OPTION (MANUAL
PULL-DOWN, POWERED FEED OR SEMI-AUTO OPERATION)
- SEMI-AUTOMATIC OPERATION PUSH BUTTONS FOR HEAD
POSITIONING
- BLADE SPEED SELECTION SWITCH
- COOLANT ON / OFF / WASH HOSE BUTTON
- E-STOP BUTTON

STANDARD MACHINE FEATURES
- ELECTRO-HYD OPERATED EASY-SWING CAST SAW HEAD
- QUICK-RELEASE CAST-IRON VISE WITH DOVETAIL WAYS
- CONTROL HANDLE WITH SAFETY SPRING-LOADED TRIGGER
SWITCH TO START OR STOP BLADE OR FEED MODE
- REMOTE FOOT PEDAL STARTS THE SEMI-AUTO CYCLE
- ROTATING TABLE WITH CUT SLOT THAT MOVES IN
TANDEM WITH SAWING HEAD
- BAND TENSION INDICATOR
- SMALL FOOTPRINT
- ROBUST STEEL BASE
- EASY-TO-READ ANGLE SCALE
- ADJUSTABLE GUIDE ARM
- PRE-SET, REPLACEABLE CARBIDE GUIDE INSERTS
- MECHANICAL BLADE TENSIONING
- TRUE DIRECT DRIVE - NO BELTS OR PULLEYS
- SAFETY DOOR INTERLOCKS
- FLOOD COOLANT
- ADJUSTABLE WORK STOP
- REPLACEABLE BLADE BRUSH

OPTIONS AVAILABLE - PRICE ON REQUEST
- MIST LUBRICATION
- ADAPTER PLATE FOR KK330 TABLE
- KK330 5' INFEED/OUT FEED ROLLER
- R2 WORK STOP FOR KK330 TABLE
- 208/575 VOLT TRANSFORMER
Power: 480 (3-Phase)
