NEW JET JDP-20VS-3 20

JET (NEW) MODEL JDP-20VS-3 20" VARIABLE SPEED
DRILL PRESS

20" DRILL TO CENTER OF CIRCLE
1-1/2" CAST IRON DRILLING CAPACITY
1-3/8" MILD STEEL DRILLING CAPACITY
10-7/16" COLUMN TO SPINDLE DISTANCE
VARIABLE SPINDLE SPEEDS
300-2000 RPM RANGE OF SPINDLE SPEEDS
4-1/2" COLUMN DIAMETER
MT-3 SPINDLE TAPER
6" SPINDLE TRAVEL
44-1/2" SPINDLE DISTANCE TO BASE
30-1/4" SPINDLE DISTANCE TO TABLE
22" X 18-3/4" TABLE SIZE
20" TABLE TRAVEL
THREE 3/8" T-SLOTS
7-7/16" T-SLOT CENTERS
154 LB WORK TABLE WEIGHT CAPACITY
27" X 19" BASE DIMENSIONS
TWO 5/8"BASE SLOTS
2 HP MOTOR, 230/460 VOLT, 3 PHASE

FEATURES
- STEEL COLUMN
- MASSIVE 3" QUILL DIAMETER
- HEAVY-DUTY CAST IRON DESIGN
- HEAD IS MASSIVELY CONSTRUCTED
- LARGE PRECISION-GROUND T-SLOT PRODUCTION TABLE
- CSA/CUS CERTIFIED
- LED MACHINE LAMP
- SPINDLE GUARD
- FRONT-MOUNTED LED SPINDLE RPM READOUT
- FRONT-MOUNTED POSITIVE CONTROL DEPTH STOP
- TABLE ROTATES 360 DEGREES AROUND THE COLUMN
- MACHINE T-SLOTTED BASE
- LARGE HAND GRIPS
- SPINDLE SAFETY GUARD
- LED MACHINE LAMP
Power: 230/460 (3-Phase)
