NEW HYDMECH DM-10

HYDMECH (NEW) MODEL DM-10 DOUBLE MITER
BANDSAW

CAPACITY - 90 DEGREES
- 8.66" X 11" RECTANGLE, 9.84" ROUND, 8.66" SQ
CAPACITY - 45 DEGREES - LEFT
- 7.87" X 8.66" RECTANGLE, 9.06" ROUND, 7.87" SQ
CAPACITY - 30 DEGREES - LEFT
- 3.15" X 5.51" RECTANGLE, 4.72" ROUND, 3.15" SQ
CAPACITY - 45 DEGREES - RIGHT
- 5.51" X 7.87" RECTANGLE, 7.87" ROUND, 6.69" SQ

1" X 9'8" BLADE
2/2.4 HP BLADE DRIVE
240 VOLTS
236 SFM BLADE SPEED - 1 SPEED
3.5 GALLON COOLANT TANK CAPACITY
34" TABLE HEIGHT

STANDARD MACHINE FEATURES
- MANUALLY-OPERATED EASY-SWING CAST SAW HEAD
- QUICK-RELEASE CAST-IRON VISE WITH DOVETAIL WAYS
- ROTATING TABLE WITH CUT LINE
- BAND TENSION INDICATOR
- MANUAL GRAVITY HEAD FEED
- REPLACEABLE BLADE BRUSH
- SMALL FOOTPRINT
- ROBUST STEEL BASE
- EASY-TO-READ ANGLE SCALE
- ADJUSTABLE GUIDE ARM
- REPLACEABLE CARBIDE GUIDE INSERTS
- MECHANICAL BLADE TENSIONING
- SAFETY DOOR INTERLOCKS
- FLOOD COOLANT
- WORK STOP

OPTION INCLUDED
- SINGLE PHASE-LIMITS USER TO HI BLADE SPEED ONLY
Power: 240 (Single)
