NEW DURMA TPL 93

Name: NEW DURMA TPL 93
Brand: DURMA
SKU: 351543
Availability: InStock

Safety note

This seller is not an Equipt Pro dealer. Equipt does not inspect items, handle payment or guarantee transactions. Verify the seller and equipment before sending funds.

Overview

Type:

Turret Punches

Manufacturer:

DURMA

Model:

TPL93

Stock #:

062893

Specifications

Dimensions	262 X 165 X 91 W/O LT BARRI	262 X 165 X 91 W/O LT BARRI
Weight	43,000	43,000

DURMA (NEW) MODEL TPL 93 TURRET PUNCH

33 TON CAPACITY
O FRAME TYPE
118" + R X AXIS MOVEMENT
59" Y AXIS MOVEMENT WITH SINGLE TOOL
393.7" AUTOMATIC REPOSITIONING RANGE
2362.2 IN/MIN SPEED OF Y AXIS
2755.9 IN/MIN SPEED OF X AXIS
4724.4 IN/MIN LATERAL SPEED Y + X
1200 MAX HIT RATE (1" PITCH, 0.39" THICKNESS
325 MAX HIT RATE (25" PITCH, .039" THICKNESS
3200 MAX HIT RATE MARKING
1.6" MAIN CYLINDER STROKE
1" MAXIMUM PUNCHING STROKE
MAX CUTTING THICKNESS (FIXED STATION)
- 0.2" MILD STEEL
- 0.1" STAINLESS STEEL
MAXIMUM CUTTING THICKNESS WITH INDEX STATION
- 0.1" MILD STEEL
- 0.06" STAINLESS STEEL
+/- 0.004" POSITIONING ACCURACY
+/- 0.002" REPEATABILITY ACCURACY
22 RPM TURRET ROTATION SPEED
150 RPM AUTO INDEX ROTATION SPEED
441 LB MAXIMUM SHEET WEIGHT
37" TABLE HEIGHT

80 GBYTE HARD DISK
4 GB SDRAM
WINDOWS 7 NETWORK SYSTEM
19" INTERACTIVE FLAT PANEL
2 USB
10/100 ETHERNET

20 HP HYDRAULIC SYSTEM MOTOR
63.5 GALLON OIL TANK
80 PSI
4 CLAMPS
2,205 LB CLAMP HOLDING FORCE
BRUSH TYPE TABLE

FEATURES
- COMMAND PEDAL
- CAD-CAM SOFTWARE AND ACTIVATOR (DONGLE)
- CONTROL UNIT, SIEMENS SINUMERIK 840 D SL WINDOWS 7 OPERATING SYSTEM
- REMOTE DIAGNOSTIC FUNCTION
- PROGRAMMING ON THE CONTROL PANEL
- AUTOMATIC CLAMP POSITIONING
- SHEET SET SWITCHES ON CLAMPS
- NETWORK, ETHERNET COMMUNICATION
- AUTOMATIC TOOL LUBRICATION
- UPS FOR CONTROL PANEL
- MOVABLE SCRAP BOX
- BRUSH TABLE
- OIL COOLER
- USB DRIVER
- REPOSITION ON X-AXIS
- ALIGNMENT TOOLS FOR INDEX STATION (D STATION)-(FOR TPL93)
- MANUAL NESTING
- LIGHT BARRIERS FOR CE

OPTIONS EQUIPMENT
- ADDITIONAL CLAMPS
- TABLE (BRUSH AND BALL)
- TOOLS, TOOL HOLDERS, REDUCERS
- CAD-CAM SW SECOND ACTIVATOR (DONGLE)
- SW FOR AUTONESTING, WHEEL AND TAPPING TOOLS
- SHEET DEFORMATION ALERT SWITCH
- TURRET COVER FOR PERFORATED SHEETS
- VACUUM SLUG REMOVER
- WORKCHUTE
- AUTOMATIC LUBRICATION FOR THE MACHINE
- AIR CONDITION FOR ELECTRICAL BOX
- LOADING - UNLOADING PREPARATION
- LOADING - UNLOADING SYSTEM
- ADDITIONAL TABLE
- SPECIAL TABLE
- TRASFORMATOR
- UPS FOR MACHINE (30 kVA - 10 MIN)
- ADDITIONAL ALLIGNMENT TOOL
