| Dimensions | 226 X 211 X 91 W/O LT BARRI | 226 X 211 X 91 W/O LT BARRI |
| Weight | 28,577 | 28,577 |
DURMA (NEW) MODEL TP123 TURRET PUNCH
33 TON CAPACITY
98.5" + R X AXIS MOVEMENT
49.2" Y AXIS MOVEMENT WITH SINGLE TOOL
15 FPM X AXIS SPEED
10 FPM Y AXIS SPEED
18 FPM LATERAL SPEED X + Y
1.6" MAIN CYLINDER STROKE
1" MAXIMUM PUNCHING STROKE
MAXIMUM CUTTING THICKNESS WITH FIXED STATION
- 0.2" MILD STEEL
- 0.1" STAINLESS STEEL
MAXIMUM CUTTING THICKNESS WITH INDEX STATION
- 0.1" MILD STEEL
- 0.06" STAINLESS STEEL
+/- 0.004" POSITIONING ACCURACY
+/- 0.002" REPEATABILITY ACCURACY
22 RPM TURRET ROTATION SPEED
150 RPM AUTO INDEX ROTATION SPEED
265 LB MAXIMUM SHEET WEIGHT
37" TABLE HEIGHT
80 GBYTE HARD DISK
4 GB SDRAM
WINDOWS 7 NETWORK SYSTEM
15" LCD COLORSCREEN SUPER VGA
2 USB
10/100 ETHERNET
20 HP HYDRAULIC SYSTEM MOTOR
63.5 GALLON OIL TANK
80 PSI
3 CLAMPS
2,205 LB CLAMP HOLDING FORCE
BRUSH TYPE TABLE
FEATURES
- PUNCHING, FORMING, TAPPING AND WHEEL TECHNOLOGY
- STRESS-RELIEVED O FRAME
- FLEXIBLE TURRET CONFIGURATIONS
- AUTO LUBRICATION OF MOVING PARTS
- RIGID GUIDES
- USER-FRIENDLY CONTROL WITH
CAD-CAM SOFTWARE
PROGRAMMABLE SHEET CLAMPING SYSTEM
