NEW VICTOR S22120S

VICTOR (NEW) MODEL S22120S PRECISION HEAVY-DUTY
LATHE

CAPACITY
- 26" SWING OVER BED
- 18-1/16" SWING OVER CROSS-SLIDE
- 33-1/4" SWING IN GAP DIAMETER
- 120 " BETWEEN CENTERS
- 15 HP, 3 PHASE SPINDLE MOTOR

HEADSTOCK
- 4 1/8" SPINDLE BORE DIAMETER
- D1-11 CAMLOCK SPINDLE NOSE
- 12 STEPS
- 15-1200 RPM

CARRIAGE
- 15" CROSS SLIDE TRAVEL
- 10" COMPOUND REST TRAVEL

MT #5 TAILSTOCK QUILL TAPER

STANDARD EQUIPMENT
- CENTER SLEEVE
- TOOL BOX WITH KITS
- DP MP CHANGE GEAR
- RAPID FEED MOTOR
- LEVELING SCREW
- THREAD DIAL INDICATOR
- DEAD CENTER MT #5
- OPERATION MANUAL PARTS LIST
- COOLANT SYSTEM

OPTIONS AVAILABLE - PRICE ON REQUEST
- 4-WAY TOOL POST
- QUICK CHANGE TOOL POST
- DIGITAL READOUT
- 3-JAW SCROLL CHUCK
- 4-JAW INDEPENDENT CHUCK
- CHUCK COVER
- STEADY REST WITH ROLLER SUPPORT
- FOLLOW REST
- FULL-LENGTH SPLASH GUARD
- FACE PLATE
- TAPER TURNING ATTACHMENT
- MICRO CARRIAGE STOP
- 4-POSITION SADDLE STOP
- HALOGEN WORK LIGHT
- LIVE CENTER
Power: (3-Phase)
