NEW VICTOR 20120S

VICTOR (NEW) MDL 20120S PRECISION HEAVY-DUTY LATHE

CAPACITY
- 20" SWING OVER BED
- 13" SWING OVER CROSS-SLIDE
- 120" DISTANCE BETWEEN CENTER
- 15-3/4" BED WIDTH

HEADSTOCK
- 3.18" SPINDLE BORE DIAMETER
- D1-8 CAMLOCK SPINDLE NOSE
- 12 SPINDLE SPEEDS
- 20~1550 RPM SPINDLE SPEEDS

CARRIAGE
- 12-1/2" CROSS SLIDE TRAVEL
- 10" COMPOUND SLIDE TRAVEL

MT 12-1/2" TAILSTOCK SPINDLE BORE TAPER

10 HP, 3 PH MAIN MOTOR

STANDARD MACHINE FEATURES
- CENTER SLEEVE
- TOOL BOX WITH KITS
- HEX WRENCHES
- GUN OILER
- CHANGE GEAR
- Z-AXIS RAPID FEED
- LEVELING SCREW AND PADS
- THREAD DIAL INDICATOR
- DEAD CENTER MT #5
- SCREW DRIVER
- 10 HP, 3 PH MOTOR
- OPERATION MANUAL PARTS LIST
- COOLANT SYSTEM
- LEVER CHANGE INCH/METRIC GEAR BOX
- INCH/METRIC DUAL DIALS

OPTIONS AVAILABLE - PRICE ON REQUEST
- FOUR-WAY TOOLPOST
- QUICK-CHANGE TOOLPOST
- AMERICAN TOOLPOST
- DIGITAL READOUT
- 3-JAW SCROLL CHUCK
- 4-JAW INDEPENDENT CHUCK
- CHUCK COVER
- STEADY REST WITH ROLLERS SUPPORT
- LIVE CENTER MT #5
- FOLLOW REST
- FULL-LENGTH SPLASH GUARD
- FACE PLATE
- TAPER TURNING ATTACHMENT
- MICRO CARRIAGE STOP
- HALOGEN WORK LIGHT
- LEVER TYPE 5C COLLET CLOSER
- 5C COLLET SET
Power: (3-Phase)
