NEW JET GH-1860ZX

JET (NEW) MODEL GH-1860ZX LARGE SPINDLE BORE LATHE
WITH TAPER ATTACHMENT

18" SWING OVER BED
11" SWING OVER CROSS SLIDE
27-1/2" SWING THROUGH GAP
60" BETWEEN CENTERS
3-1/8" HOLE THROUGH SPINDLE
D1-8 SPINDLE MOUNT
MT-7 (MT-5) SPINDLE TAPER (WITH SLEEVE)
12 SPINDLE SPEEDS
25 - 1,800 RPM SPINDLE SPEEDS
122 LONGITUDINAL AND CROSS FEEDS
0.0015-0.0900 LONGITUDINAL FEEDS
0.0006-0.0360 CROSS FEEDS
61 INCH THREADS
1-5/8 - 72 INCH THREADS
24 METRIC THREADS
0.05 - 20 METRIC THREADS
1 X 1 MAX TOOL SIZE
5-1/8" MAX COMPOUND SLIDE TRAVEL
9" MAX CROSS SLIDE TRAVEL
55-9/16" MAX CARRIAGE TRAVEL
5" TAILSTOCK SPINDLE TRAVEL
MT-5 TAPER IN TAILSTOCK SPINDLE
7-1/2 HP, 3 PHASE, 230/460 VOLT MAIN MOTOR

STANDARD EQUIPMENT
- 10" 3 JAW CHUCK W/TOP REVERSING JAWS
- 12" FACE PLATE
- 5 PC QUICK CHANGE TOOL POST SET
- FOLLOW REST
- LARGE CAPACITY STEADY REST W/BALL BEARINGS TIPS
- FULLY INTEGRATED COOLANT SYSTEM WITH
FULL- LENGTH SPLASH GUARD
- LARGE EASY TO USE FOOT BRAKE
- ARTICULATING LED WORK LAMP
- CENTRALLY LOCATED CONTROLS WITH JOG BUTTON
- THREADING DIAL
- MOUNTING PADS AND LEVELERS
- SPINDLE SLEEVE (MT-7 TO MT-5)
- ELETRONIC CHUCK KEY HOLDER
- FITTED TOP MATS TO HOLD TOOLING
- CENTRALLY LOCATED CONTROLS WITH JOB BUTTON
- THREADING DIAL
- MOUNTING PADS AND LEVELERS
- LIVE CENTER
- TOLERENACE TEST CERTIFICATE
- TOOL BOX AND ADJUSTING TOOLS
- E-STOP ON CARRIAGE FOR ADDED SAFETY

FEATURES
- 3-1/8" BORE SPINDLE IS SUPPORTED BY TWO TAPERED
AND ONE BALL BEARING
- CHROME MOLYDBENUM HEADSTOCK GEARS ARE HARDENED,
GROUNDS, AND SHAVED
- UNIVERSAL GEARBOX ALLOWS INCH, METRIC, AND
DIAMETRAL PITCH THREADS
NO CHANGE GEARS REQUIRED
- CARRIAGE FEATURES ONE-SHOT LUBRICATION AND
TURCITE-B ON BED SLIDING SURFACES
- T-SLOTTED COMPOUND SLIDE FEATURING A 4-WAY TOOL
POST
- ONE-PIECE CAST IRON BASE ABSORBS VIBRATION
ALLOWING HEAVIER CUTS
- HIGH QUALITY ANSI CLASS 50 WEAR-RESISTANT
CAST IRON BED WAYS ARE HARDENED AND GROUND
- REMOVEABLE GAP ALLOWS LARGER DIAMETER WORK
- FIVE POSTION AUTOMATIC CARRIAGE STOP INCREASES
PRODUCTIVITY
- MEEHANITE CASTINGS
- SIEMENS ELECTRICS
Power: 230/460 (3-Phase)
