STANDARD FEATURES
• Mitsubishi M730 VS-L CNC control unit with 10.4” Color LCD Display
• SSS Control “Super Smooth Surface” for determining appropriate shapes and avoiding unnecessary decelerations.
• Nano Interpolation (Controls the machine in the least command increment of 1nm.)
• OMR Control (High Speed and Accuracy Control of driving system by estimating paths of machine-end.)
• High-Speed Microprocessor CNC System
• 45° Slant bed design provides extra rigidity for heavy machining.
• Two spindles and two turrets
• 10-Axis simultaneous machining plus 2 axes for CNC controlled gantry parts catcher
• Independent dedicated Y-axis slides for increased speed and flexibility
• Main spindle for first operation work
• Sub-spindle for secondary operation work. Equipped with “Superimposition”
• C-Axis on main and sub with scale feedback.
• Disk brakes on both main and sub-spindles
• Automatic part transfer from the main spindle to the sub spindle, round stock or irregular shapes.
• CNC controlled gantry parts catcher driven by programmable servo motor.
• Parts conveyor
• Programmable parts catcher
• Rigid tapping on main spindle, Sub-Spindle, and live tooling spindles.
• Sub-Spindle ejector and Coolant through the spindle clean out.
• 7,000 RPM main spindle and 7,000 RPM Sub-Spindle Speeds
• 15 HP Integrated spindle motor on the main and the synchronized Sub-Spindle
• 6,000 RPM, Hi-Torque 6-HP live tool drive
• 12-Station upper turret (12-live tooling)
• 12-Station lower turret (12-live tooling)
• 0.10 Seconds/ Station turret indexing
• Air conditioned electronics cabinet.
• Eurotech Gap Elimination Ladder Logic for faster cycle time
• Free lifetime programming classes
• Free online phone support for both maintenance and programming
• 1-year warranty on machine / 2-year control warranty
