NEW EUROTECH B1250L

STANDARD FEATURES
⦁ Eurotech-Fanuc EASY Plus Control, 15” LCD color touch screen and full keyboard.

⦁ Tool load monitoring system10.4” Graphics parts cutting display.

⦁ Extended editing functions; merge, change, move, copy.

⦁ 32-bit CPU high-speed Pentium microprocessor CNC System

⦁ 3,000 RPM main spindle speed

⦁ 51 Horsepower wide range constant output spindle motor and gear box

⦁ 16 station turret

⦁ 0.3 seconds/station turret indexing

⦁ 945 IPM B axis rapid traverse

⦁ 945 IPM Z axis rapid traverse

⦁ 709 IPM X axis rapid traverse

⦁ 295 IPM Y axis rapid traverse

⦁ 15” 3 jaw chuck on main spindle

⦁ Rigid tapping: main, and live tool spindles

⦁ High pressure coolant system

⦁ Set of static and live tool holders

⦁ Programmable tool probe system

⦁ Revolving tool attachment for live spindle tooling

⦁ Revolving tools driven by 23.5 horsepower built in spindle drive motor inside turret disc thermally stabilized by cooling unit

⦁ 16 revolving tool stations

⦁ C-axis control on main

⦁ (1) X axis mill/drill tool & (1) Z axis mill/drill tool

⦁ Air conditioned electronics cabinet

⦁ Chip conveyor

⦁ Eurotech gap elimination ladder logic for faster cycle time

⦁ Free lifetime programming classes

⦁ Free online phone support for both maintenance and programming

⦁ Hydraulic Tailstock is fully CNC-operated. The tailstock is positioned into machining area by the Z axis slide and hydraulically locked at the desired position.

⦁ 1 year warranty on machine

Model: B1250L
Maximum bar capacity: 3.74”
Maximum machining diameter: 17.8”
Maximum machining length: 46”
Maximum swing over diameter (bench): 26.7”
Spindle Bore: 3.74”
Spindle speed range: 3,000 RPM
Geared headstock: 1:1 and 4:1
Spindle motor: 51 HP
Motor type: Wide range
Spindle nose: ASA A2-8
Turret indexing time 1 station: 0.3 sec/pos
Turret indexing type: Bi-directional
Number of stations: 16
Positioning travel: 51.2”
Quill Stroke: 6”
Quill diameter: 4.5”
Cylinder area: sq. in 17.23
Max Thrust: 2,645.5lbs
Flange for live center: MT5
Number of positions: 16
Drive motor-max. rating (Fanuc): 23 HP
Speed range: 6,000 RPM
Engagement time: immediate
Spindles: Main
Spindle positioning: Full “C”
Minimum command increment: 0.001 degree
Positioning system: Spindle motor
Degree of movement: Programmable
Rapid speed rate: 100 RPM
Voltage required: 400 volt AC, 3-phase
Air required: 80 psi @ 4 CFM
Width: 86.2”
Height: 87.5”
Length with chip conveyor: 218”
Machine weight with chip conveyor: 18,519 lbs.
Z axis repeatability accuracy: +/-.00004”
X  axis positioning accuracy: +/-.00006”
C axis positioning accuracy: +/-.00005°
C axis repeatability: +/-.00001°
