NEW HYUNDAI WIA L400A

Hyundai Wia L400A
Features
Sturdiness secured through the adoption of an all axis box guide
All-in-one type structure with direct link for high accuracy and sturdiness
Based on double anchor method for high accuracy pretension
Minimized heat deformation in the main spindle
Two-Step gear box drives the main spindle across the L400 range. (L400MA : Belt)
Big Bore Spindle (L400C Series)
Specifications
Specifications are subject to change without notice for quality improvement.

In case of any further information, please refer to the machine catalogue.

Max Turning Dia: 640 mm
Max Turning Length: 1,180 mm
Chuck Size: 12″ inch
Driving Method: GEAR
Spindle RPM: 3,000 r/min
Spindle Output: 26/22 kW
Spindle Torque: 1,325/1,120 N.m
Travel(X/Z): 325/1,205 mm
Rapid Travel(X/Z): 20/25 m/min
Slide Type: BOX
No. of Tools: 12 EA
Tool Size: 25/50 mm
