| X-Axis | 23.62" | 599.95 mm |
| Y-Axis | 17.72" | 450.09 mm |
| Z-Axis | 17.72" | 450.09 mm |
| # Axis | 5 | 5 |
| Spindle Motor | 53 hp | 39.5 kW |
| Spindle Speed | 20,000 RPM | 20,000 RPM |
| ATC Capacity | 30 | 30 |
| Taper | HSK63A | HSK63A |
Heidenhain iTNC 530 w/ Ethernet & Electronic Handwheel
5-Axis Simultaneous
3D Touch Probe
Blum Laser Tool Presetter
Direct Measuring System Heidenhain X/Y/Z Glass Scales, B/C Rotary Encoders (1um Resolution)
7 Pool System 3R Dynafix Pallet Changer
1000 psi Through Coolant Spindle
172 Gallon Band Filter Coolant Tank
High Capacity Chip Conveyor
MQL System
Oil Mist Extractor
External Spindle Chiller
Spray Gun
400V transformer
Blum Calibration Tool
All Documents & Parameter Backups
