| Rect-Cap (H) | 12.7" | 322.58 mm |
| Rect-Cap (W) | 114.9" | 2,918.5 mm |
| Rounds-Cap | 12.7" | 322.58 mm |
| Square-Cap | 12.7" | 322.58 mm |
| Power | 5 hp | 3.7 kW |
| Type (Auto, Manual, Semi) | Auto | Auto |
| Blade Width | 1.25" | 31.75 mm |
| Blade Thickness | 0.042" | 1.0668 mm |
| Blade Length | 150.4" | 3,820.2 mm |
| Dimensions | 91”L x 82”W x 53”H | 91”L x 82”W x 53”H |
| Weight | 3,836 LBS | 3,836 LBS |
Maximum Cutting Capacity-
Round 12.7”
Square 12.7” x 12.7”
Rectangular 12.7” x 14.9”
Bundle Capacity Width 7.4” to 11.8”
w/ optional top clamps Height: 2.7” to 5.5”
Remnant Piece 2”
Blade-
Variable Speed 60 - 328 fpm
Size 12’ 6.4” x 1.25” x .042”
Motor-
Saw Blade 5 HP
Hydraulic 1 HP
Coolant 1/8 HP
Auto. Material Feed System-
Job Storage Up to 100 jobs
Single Index Stroke 0” to 15.8”
Multiple Stroke Indexing 0” to 999”
(Automatic kerf compensation)
Weight 3,836 LBS
Power 230V, 3 PH, 60 Hz
(460, 3 PH, 60 Hz Option)
Floor Space 91” x 82” x 53”
Work Bed Height 28.7”
Optional Accessories*
Variable Vise Pressure Control System $ 1,395.00
Hydraulic Top Clamps for Machine & Index Vises (C325H-24000) $ 3,495.00
Heavy-duty Roller Table 5’ long (Part# RT-5-19PM) Capacity- 4200lbs $ 2,895.00
Heavy-duty Roller Table 6’ 6" long w/vertical Rollers
(Part# 05RC-4470-2M) Capacity- 5500lbs $ 3,595.00
Heavy-duty Roller Table 10’ long (Part# RT-10-19PM) Capacity- 7700lbs $ 4,395.00
Micro Droplet Applicator $ 3,495.00
Cosen Cool Misting Fluid 1 gal $ 99.00
Cosen Cool Misting Fluid 5 gal $ 449.00
Buck Boost Transformer for incoming power of 208V or below $ 1,895.00
Voltage change to 460V 3PH $ 995.00
QR Code Reader (Part# EP-QRCODE-1) $ 3,495.00
*pricing on optional accessories valid only when purchased with machine. Pricing may differ when
purchased individually without machine.
