Max Cutting Length: 10"
Max Capacity Mild Steel: 1/4"
Max Capacity Stainless Steel: 3/16"
Min Notching Thickness: 22 Ga.
Notching Angle, Fixed: 90 degree
Stroke per Minute: 27
Table Dimensions: 33 x 27
Oil Tank Capacity: 9 Gal.
Main Motor: 7.5 HP, 3 Phase, 220V/25A (optional 440V/15A)
Machine Dimensions: 39 x 38 x 49"
Machine Weight: 2650 lbs.
Standard Features:
ISO 9001 certified
Super large table
Milled table surface with engraved scales on left and right side of the table top
12” combination hold down and stop bars
All steel construction
Safety finger guards
(2) quick change gauges
Foot pedal control
Quiet hydraulic system
One year warranty
