Our customers were instrumental in identifying changes along the multi-year process of developing this machine. It continuously performed in high usage settings with multiple operators, cutting continuously throughout the day.
Standard Equipment
10 ft. welded steel frame.
Chrome-plated 1 3/4″ guide tubes.
8 Nylatron roller bearing systems.
Adjustable vertical and horizontal rulers.
Quick change from vertical to horizontal cutting.
Thin material pressure guard.
Solid aluminum material rollers.
Enclosed counterweight system.
Integrated dust collection system.
Weight598 lbsDimensions124 x 17 x 92inMax. Crosscut64"/1625mm
Max. Rip CutUnlimited
Cut Depth1 ¾"/45mm
Cut Accuracy1/64"/.4mm
Frame Length120"/3050mm
Daily UsageContinuous (8+ Hours)
Rollers14
Saw Blade Diameter8"/210mm
Motor amps and voltage20 amp, 120 volt, 10 amp 240 volt
Motor Horsepower (HP)3 HP
Blade RPM500-5,500 revolutions per minute
Diameter of dust collection kit1.5"
Country of Origin USA
