Convenient Saw Frame Replacement
The front and rear machine plates can be separated to facilitate mounting or dispatching of the saw frame.
Upper roller is driven by chain.

Quick and Safe Design to Changing Blades

Automatic Lubrication of Main Saw Frame.
Lubrication Frequency as Digitally Controlled.
Feed rollers are driven by a servomotor.
Sawblade running speed accuracy matches feed speed.
Accuracy and reliability of cutting by providing consistent lubrication.

Convenient Control Panel
The centralized control panel provides maximum operator convenience. Major control functions include: feed speed display, feed speed regulation, timer, start and stop controls, emergency stop and air control.

Rear Pressure Roller Height Adjusting System

Upper Feed Roller Adopts Chain Drive with Chain Allowance Automatic Compensation System Attached

Micro Computer Temperature Control Display
Each slider with a temperature indicator, if 4 blades exceed a temperature over 46°C a warning light will flash.
The operator will then stop the machine safely and check the system.

Efficient Dust Removal
The upper and lower air blast nozzles, provided at the back side of the blades, are used for cooling blades and removing saw dust. 5”x5 hold dust chutes are equipped on the machine.

Rugged Structure
The saw frame is manufactured from durable aluminum alloy, permitting continuous operation and long life.

Feed Fences Can Be Changed to Suit Various Wood Materials

Convenient Design for Loading, Unloading, and Adjusting Blades

Feed Rolls & Pressure Rolls

Bottom Rolls – 7 pieces in Front Section & 5 pieces in Rear Section

Top Front section is equipped with 7 pressure rollers & 3 air cylinders controlled by sensor

Top Rear section is equipped with 5 pressure rollers & 1 air cylinder controlled by sensor

SPECIFICATIONS:

Model FR200

Main Motor 25HP

Feed Motor 7.5 HP (servo)

Machine Opening Motor 0.5 HP

Max. Working Thickness 205mm

Min. Working Thickness 70mm

Max. Working Width 150mm

Min. Working Length 400mm

Feed Speed 0.1~2 m/min

Saw blade Speed 480 stroke/min

Saw blade Stroke 210mm

Saw blade Size 500 x 40 x 0.7~0.9mm, Kerf:1.1~1.4mm

Saw Kerf Size Stellite or TCT

Max. Number of Blades 24 pieces

Finished tolerance +/- 0.1mm

Min precision thickness 2.0 mm

Dust pipe size 5” (4)

Electrics To be confirmed at time of order

Machine Dimensions 3700 x 1000 x 1900mm

Packing Dimensions 3900 x 1600 x 2200mm

Net Weight 4200 kgs

Gross Weight 4400 kgs

STANDARD EQUIPMENT:
Servo feed system
Microcomputer lubrication control
Side temperature monitoring system
Automatic lifting of the idler system
Electro-optical switch cleaner
Side cooling system
Lock saw frame
Side plate
Center plate
Feeding track
Saw blade spacer
Feed bushing
Side cooler

OPTIONAL EQUIPMENT ON REQUEST:
·         Automatic Saw Blade Sharpener
·         Saw Blade Tensioner
·         Slide Cooler
