Head Pick up Station
TUPC CNC Indexing Micro Head
A-Axis 360.000 x 0,001 Gr
C-Axis 360.000 x 0,001 Gr
SELS Spindle extionsion L=500 mm
CTS Internal coolant system
ATC Chain Tool changer 60 Positions
Hydrostatic guideways
Optional T Slotted floorplates 5600 x 1875 (2x) + 4000 x 1875 mm
X-Axis: 16.000 mm
Y-Axis: 3.500 mm
Z-Axis: 1.500 mm
Power on spindle: 80 kW
Spindle speeds: 4000 Rpm
Spindle Taper: Sk59 ISO/Bt/Mk
Feed rate X-Axis: 25000 mm/min.
Feed rate Y-Axis: 25000 mm/min.
Feed rate Z-Axis: 25000 mm/min.
Millinghead auto-index: 2.5 x 2.5 °
Length: 24000 mm
Width: 6500 mm
Height: 6500 mm
