USED TRIA TR 120 49

🏭 Manufacturer Information

Manufacturer: Tria S.p.A.

Model: TR 120 49

Condition: Used (Excellent, industrial-grade)

Country of Origin: Italy

Drive Motor: 50 HP (approx. 37 kW)

Voltage: 460V / 480V, 3-Phase

Frequency: 60 Hz

⚙️ Product Description

The Tria Model TR 120 49 Granulator is a heavy-duty, high-throughput granulation system designed for processing plastics and other materials in demanding industrial environments. Featuring a water-cooled cutting chamber, tungsten-tipped knives, and sound reduction casing, it delivers quiet, efficient, and consistent size reduction performance.
Built with an open rotor design (5 rows × 2 knives = 10 total) and 4 stator knives (2 front, 2 rear), this model is ideal for processing thermoformed scrap, film, sheet, or molded components. With a throughput capacity of up to 1,200 kg/hr, the TR 120 49 provides exceptional reliability and energy efficiency.
The soundproofed steel enclosure and large discharge screen minimize noise while maximizing output. A rear trap-door feed system enables seamless integration into thermoforming or extrusion lines, ensuring smooth and safe operation.

📏 Specifications

Rotor Diameter: 490 mm

Rotor Width: 1,200 mm

Feed Opening: ~970 mm (W) × 120 mm (H)

Rotor Type: Open rotor, 5 rows × 2 knives (10 total)

Stator (Bed) Knives: 4 total (2 front, 2 rear)

Drive Motor: 50 HP (37 kW)

Voltage: 460V / 480V, 3-Phase

Frequency: 60 Hz

Cutting Chamber: Water-cooled

Throughput Capacity: Up to ~1,200 kg/hr (varies by material & screen size)

Screen Area: Large, high-throughput discharge design

Feed System: Rear trap-door (ideal for thermoforming integration)

Knife Material: Tungsten-tipped (extended wear life)

Noise Reduction: Fully enclosed, sound-insulated casing

Construction: Heavy-duty steel with hinged access doors

Sound Enclosure: Yes, complete sound reduction casing

🧩 Applications

Plastic granulation and recycling

Thermoforming scrap recovery

Injection molding regrind

Film and sheet extrusion trimming

PET, PVC, HDPE, PP reprocessing

Compounding and blending prep

Automotive plastic waste recovery

Packaging and container regrind

Industrial waste reduction

Recycling plant integration

♻️ What Might This Be Used For

This Tria TR 120 49 is ideal for recycling plastic production waste such as thermoformed sheet offcuts, runners, sprues, or edge trim. It can be integrated into extrusion and thermoforming lines to reduce material size for reintroduction into production, minimizing waste and material cost.

🧱 Products That Could Use This Machine

PET sheet and bottle scrap

PP and HDPE containers

PVC pipe and profile trimmings

ABS and polycarbonate components

Packaging film regrind

Thermoformed trays and cups

Automotive plastic parts

Injection molded housings

Plastic caps and closures

Industrial recycling material
