| Swing | 750 mm | 29.528" |
| Machining Length | 580.5 mm | 22.854" |
| Chuck Size | 10" | 254 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 3,500 RPM | 3,500 RPM |
| Turning Dia | 425 mm | 16.732" |
| Control | CNC (Fanuc 0i-TF Plus) | CNC (Fanuc 0i-TF Plus) |
| Dimensions | 1,800mm x 3,753mm x 1,850mm | 1,800mm x 3,753mm x 1,850mm |
| Weight | 8,050 kgs | 8,050 kgs |
Specifications (subject to buyer verification):
Swing over bed: Ø690
Max Cutting Diameter: Ø400
Standard Cutting Diameter: Ø221
Max Cutting Length: 1,060mm
Chuck Size (Main): 10"
Type of Spindle Nose: A2-8
Max Spindle Speed: 3,500 RPM
Through Spindle Hole Diameter: Ø91
Max Bar Size: Ø81
Spindle Bearing Inner Diameter: Ø140
Spindle Motor: 18.5 / 15 kW
Number of Tool Station: 12 (24 Positions Index)
Tool Size (Out Dia x Boring bar size): □25 × Ø40mm
Turret Indexing Time: 0.344 sec/step
Rapid Traverse: (X / Z): 30 / 30
Max. Stroke (X / Z): 240mm / 1,200mm
Feed Motor (X / Z): 3.0 / 3.0 kW
Tailstock Stroke: 1,080mm
Cylinder Dia: Ø100mm
Quill Stroke: 120mm
Quill Taper: MT#5
Spindle Motor: 5.5 / 3.7 kW
Max Spindle Speed: 5,000 RPM
Max Drill/Tap Size (Endmill / Collet size): Ø20 / ER 32
Min. Index Angle: 0.0001 deg
Tank Capacity Lubrication: 12L
Tank Capacity Hydraulic: 11L
Coolant: 150L
Electrical Power Supply: 35 kVA
Dimensions: 1,800mm x 3,753mm x 1,850mm
Weight: 8,050 kgs
Equipped With (subject to buyer verification):
Fanuc 0i-TF Plus Controller
Air Gun
ID Holder
